Back Panel Connectors
Descriptions of the Back Panel Connectors
ETHERNET RJ-45 female port for connection of Ethernet cable
USB USB ‘B’-type port. Connects through USB cable to a
computer’s USB ‘A’-type port.
CATV RF connector to attach the cable for broadband Internet
access
POWER Jack to connect the power adapter included in the product
package
Caution! You must use the 12VDC/1.25A power adapter that
comes with the DCM-201 cable modem. Using the
wrong power adapter can damage the cable modem.
RESET Restores factory default settings
Ethernet Port
Receptor for Power Adapter.
USB Port
Receptor for CATV.
Reset Button
