OUTPUT
• Surge: IEC61000-4-5
• ESD: IEC61000-4-2
• Dimensions:
• 5.5×3.4×5.9inches (W×H×L)
• 150 × 86 × 140 mm (W × H × L)
• EMI/RFI: FCC part 15 Class B,EN55022 Class B
• Power Good Delay Time: 100~500mS
• Power Fail Delay Time: >1ms
• Hold-up Time: 16ms Min.
• Line Regulation: ±1%
• Over Current Protection:
• Increase the output current at the +5V rail gradually to
30A~48A. The main output should shutdown
• Increase the output current at the +12V1 rail gradually to
15A~25A. The main output should shutdown
• Increase the output current at the +12V2 rail gradually to
15A~25A. The main output should shutdown
• Increase the output current at the +3.3V rail gradually to
30A~50A. The main output should shutdown
• Over Voltage Protection:
• +5V:7.0V
• +3.3V:4.3V
• +12V:15.6V
• Short Circuit All output to GND
• Hi-Pot Voltage 1500 Vac, Time 2-3 Sec. cut off current 10 mA MAX.
C
ONNECTORS
• Detachable 24 pin to 20 pin ATX power connector
• 6 standard 5 1/4-inch drive connectors
• 1 standard 3 1/2-inch drive connector
• 1 standard SATA drive power connector
• 1 PCI-Express graphic card power connector
• 4 pin Intel P4 style power connector
Legal notices
Limited 1 Year Warranty
Dynex warrants that for 1 year from date of purchase as stated on your
receipt, it will replace this product if found to be defective in materials or
workmanship. If defective, return the item to the store where it was
purchased before the expiration of the 1 year warranty period, with your
original receipt, and we will replace it with a then-current equivalent
Dynex product (or a pro-rated refund at Dynex's option). This warranty is
available only for the original purchaser of this product. Dynex will not
be responsible for any incidental or consequential damages or for any
loss arising in connection with the use or inability to use this product.
Some states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or
exclusion may not apply to you. For defective products purchased online,
please contact:
www.dynexproducts.com
Dynex support service at 1-800-305-2204. Dynex, Richfield,
Minnesota
Copyright and disclaimer
© 2005 Dynex. DYNEX and the DYNEX logo are trademarks of Best Buy
Enterprise Services, Inc. Other brands and product names are trademarks
or registered trademarks of their respective holders. Specifications and
features are subject to change without notice or obligation.
Voltage Min. load Max. load Regulation Ripple
and Noise
+3.3V 30A 0.5A ±5% 50mV
+5V 28A 0.3A ±5% 50mV
+12V1 14A 1A ± 5% 120mV
+12V2 15A 1A ±5% 120mV
-5V 0.3A 0A ±10% 100mV
-12V 0.3A 0A ±10% 120mV
+5Vsb 2.0A 0A ± 5% 50mV
