2-13
Accessing the VESA Mounting Interface
If you want to convert your desktop monitor to a wall mount or kiosk monitor, follow the steps below to
access the VESA mounting interface.
Note: You will need a screwdriver for the following steps:
1 Remove the back cover of the stand by pulling forward on the bottom cut-out.
2 Carefully lay the monitor face down. At the top of the mounting screw cover there are two slots.
With a screwdriver, pry open the mounting screw cover. The cover fit is tight so remove it carefully.
3 When you remove he mounting screw cover, you will see four screws. Remove the screws to mount
your monitor. Refer to the drawing on page 18.
The following companies provide VESA mounting devices compatible with your touchmonitor:
Ergotron Innovative Office Products
800-888-8458 800-524-2744
651-681-7600 610-253-9554
www.ergotron.com www.innov-office-prod.com
GCX MRI
800-228-2555 800-688-2414
707-773-1100 www.mediarecovery.com
www.gcx.com
Mounting the Base
You can also mount your touchmonitor by using the keyholes in the base of the stand. These keyholes
provide easy slide on mounting. You can also bolt your touchmonitor to a tabletop or other flat surface.
Please refer to Appendix C for location and dimension of the mounting holes.
