Operation
54
6.2.1 Main screen function descriptions
Figures 55 and 56. provide descriptions and locations of the information and functions available
from the Main screen and the Fault Screen.
Figure 55 Main screen functions
Figure 56 Fault screen functions
Liebert FS
48020
RPM:
SOC:
SOC:
BUS:
PWR:
73.4%
545V
12.3kW
SHUT DN MENU
F1 F2 F3 F4 F5 F6
MODE:
STATUS:
DISCHARGE
OK
START LOCK
D V U C P
Status
Message
Current Operating Mode
Option Status
Current Security Level
Contactor Status
PWM
Status
Charge
Status
Internal
Bus
Voltage
Menu
Button
Panel Lock/Unlock Button
Shutdown Button
Startup Button
Liebert FS
48020
RPM:
SOC:
SOC:
BUS:
PWR:
73.4%
545V
12.3kW
CLEAR MENU
F1 F2 F3 F4 F5 F6
MODE:
STATUS:
FAULT
2 FAULTS
MORE
D V U C P
Fault Status Message
Fault Clear Button
More Information
Button
Bus
Power
