EN-8500
11
3.
Attaching The Optional Wall Mount Arm (not supplied):
Follow these steps to finish installing the wall mounting arm:
1. Place the wall mounting arm onto the back of the monitor. Line up the
holes of the arm with the holes in the back of the monitor.
2. Insert the 4 screws into the holes and tighten.
3. Insert the cables into the slot on the back of the monitor.
NOTE:
The Envision EN-8500 is in compliance with the most current revision of the
VESA 100mm Flat Panel Monitor Physical Mounting Interface Standard,
“FPMPMI Standard”. It is also compatible with the Ergotron line of mounting
and arm solutions. Visit their website at www.ergotron.com
for more
information on the many ways on which you can mount this monitor.
INSTALLATION INSTRUCTIONS (cont)
