Battery User's Guide
2.6 Reducing Power Consumption
Although your notebook (together with the operating system) is capable of power
conservation, there are measures you can take to reduce the power consumption:
• Use the AC power whenever possible.
• Lower the intensity of the LCD backlight. A very bright screen translates to higher
power usage.
• Try to use the HDD or the PCMCIA drive to read and write files, instead of using
the external USB FDD.
Note: The battery pack should be locked in the battery compartment all the time.
2.7 Removing The Battery Pack
This battery pack can easily be removed and replaced. Make sure that the computer is
properly shutdown before changing the battery pack. If you would like to change the
battery pack while power is on, make sure this battery pack is not the only electrical source
to the system unit. Follow the steps below to remove the battery pack.
• Have the system properly shutdown.
• Flip the system upside down as
shown.
• Press the handle to release battery
latch as shown by #1.
• Maintain the handle in released
position.
• Push the battery latch to unlock as
shown by #2. The battery pack would
pop up a little bit.
• Remove the battery pack as shown by
#3.
To insert the battery pack, reverse the steps above.
Page 2-4
