M L C 5 2
MLC 52
Back Panel
Over view
MLC 52
Front Panel
Display ON/OFF
Clearly labeled buttons make it easy
and convenient to turn the display on
and off, eliminating the need for an
external display remote
Volume Control
Provides up and down volume
control of the display. If volume
control is not required, or additional
source switching is needed, these
buttons can be configured for input
selection or other commands
Optional Mount
An optional MLM 52 VC mounting kit
can provide a separate volume knob to
control Extron MPA – Mini Power Amp
series amplifiers
Inactivity timer for
display shut-off
Adjustable timer controls
automatic shutdown to conserve
energy, prevent plasma burn-in, or
extend projector lamp life
Configuration Port
Allows for configuration of the
MLC 52 via the front panel
Multiple Memories
Each button can store up to four IR
or serial RS-232 commands
Backlit Buttons
Illuminated buttons can be custom-
labeled with supplied label insert
sheets for easy identification. These
buttons are helpful for presenters in
low-light environments
Compact Size
One-gang design easily
mounts in a wall or lectern
Built-In IR Emitter/Receiver
Enables IR learning of commands from
IR remote controls. Also provides IR
beaming for controller-to-controller
configuration without software
Status LEDs
Provide status of IR learning
and configuration
Serial RS-232 and IR Ports
Provides serial RS-232 and
IR universal display control
IR Remote Control Input Port
Hardwired IR input for control with
optional IR 402 and IRL 20 or IR Link
Black and White
Includes black and white high
impact plastic faceplates and mud
ring mount brackets
