specifications
Specifications are subject to change without notice.
© 2007 Extron Electronics. All rights reserved. All trademarks mentioned are the property of their respective owners.
M L C 5 2
Specifications
CONTROL/REMOTE — MLC CONTROLLER HOST PORTS
Serial control port ........................................... 1 front panel 2.5 mm mini stereo jack
(tip-ring-sleeve)
Baud rate and protocol ..................................... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations ........................ Mini stereo jack: tip = TX, ring = RX,
sleeve = GND
Program control ............................................... Extron’s configuration program for Windows
®
Extron’s Simple Instruction Set (SIS
)
CONTROL — PROJECTOR/PLASMA (MLC 52 RS)
Projector control port ....................................... (1) 3.5 mm direct insertion captive screw
connector, 6 pole for IR and 1-way RS 232
control (port is shared between power input and
IR and 1-way RS-232 projector control)
IR control ........................................................ TTL level (0 to 5 V) modulated infrared control from 30 kHz
up to 1 MHz
RS-232 control RS-232 control (1-way) ............ ±5 V
Baud rate and protocol (RS-232) ...................... 57600 to 1200 (9600 default) baud (configurable);
8 (default) or 7 data bits;
1 stop bit (±5 V); no parity (default), or even or odd parity
IR learning frequencies..................................... 30 kHz to 62 kHz
IR learning distance ......................................... 4" (10 cm) to 14" (36 cm) from the front panel
CONTROL — PROJECTOR/PLASMA (MLC 52 IR)
Projector control port ....................................... (1) 3.5 mm direct insertion captive screw connector,
6 pole for IR (port is shared with power input)
IR control ........................................................ TTL level (0 to 5 V) modulated infrared control from 30 kHz
up to 1 MHz
IR learning frequencies..................................... 30 kHz to 62 kHz
IR learning distance ......................................... 4" (10 cm) to 14" (36 cm) from the side panel
GENERAL
External power supply ...................................... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable;
to 12 VDC, 1 A, regulated
Power input requirements ................................ 12 VDC, 0.15 A
Rack mount ..................................................... No, but wall- and furniture-mountable
Enclosure type ................................................ High-impact plastic or metal
Enclosure dimensions
MLC 52 faceplate ........................................ 4.5" H x 2.75" W x 0.13" D (11.4 cm H x
7.0 cm W x 0.3 cm D) (1 gang)
MLC 52 VC faceplate ................................... 4.5" H x 4.6" W x 0.1" D (11.4 cm H x
11.7 cm W x 0.3 cm D) (2 gang)
Device............................................................. 2.5" H x 1.6" W x 1.5" D (6.4 cm H x 4.1 cm W x
3.8 cm D) (Depth excludes connectors and buttons.)
Product weight ................................................ 0.2 lbs (1 kg)
Shipping weight ............................................... 3 lbs (2 kg)
Vibration ........................................................ ISTA 1A in carton (International Safe Transit Association)
Listings ........................................................... UL, CUL
Compliances ................................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................................................. 30,000 hours
Warranty ........................................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%
GENERAL (CONT.)
Model Version Description Part Number
MLC 52 IR IR Control - Black & White......................................................... 60-744-02
MLC 52 RS IR and RS-232 Control - Black & White ......................................
60-744-12
MLC 52 IR VC IR and Volume Control - Black & White ......................................
60-745-02
MLC 52 RS VC IR, RS-232, and Volume Control - Black & White ........................
60-745-12
Optional Accessories
CFG Cable 9 DB Female-2.5 mm TRS Config Cable - RS Version Only ......... 70-335-01
IPL TS 2 Two Serial Port IP Link Ethernet Control Interface .......................
60-544-01
IR Link Wall-Mountable IR Signal Repeater ............................................
60-404-02
IR Sensor Remote IR Receiver ..................................................................
70-223-01
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - Black & White 70-527-02
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - Black Metal ..
70-538-02
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - White Metal ..
70-538-03
MLM 52 1GWP Metal One-Gang Wall Mounting Kit for the
MLC 52 Series - Black .............................................................
70-498-02
Included Accessories
12V, 1A
power supply 100-240VAC, 50/60Hz, to 12VDC,1A, wire ................................
70-055-01
MLC 52 Series
Button Labels Text and Icon Labels .................................................................
33-1262-01
International Labels MediaLink International Faceplate Labels ...................................
33-1167-0X
IR Emitter and
Shield Kit IR Emitter Kits ..........................................................................
70-283-01
Plastic Mud Ring Black & White ..........................................................................
70-519-X1
