www.gateway.com
OSD menus
OSD Menu Description
BRIGHTNESS. Adjusts the amount of light in the
darkest portion of the picture. Use the lowest
brightness setting you are comfortable with to
maximize the life of the monitor backlights.
You may need to readjust brightness after the monitor
has warmed up.
CONTRAST. Adjusts the level of white between the
lightest and darkest portions of an image.
PRESET. Adjust the color temperature.
9300K is bluish white.
6500K is reddish white (default).
RED, GREEN, BLUE. Customizes the color levels.
Press
the button to move to the next color.
GAMMA. Customizes the gamma level. High gamma
levels increase white levels and low gamma levels
increase contrast.
VERTICAL POSITION. Moves the display image up
and down.
HORIZONTAL POSITION. Moves the display image
left and right.
You can also use the AUTO/SELECT button to
configure the vertical and horizontal position
automatically.
CLOCK. Minimizes any vertical bars or stripes visible
on the screen background. The horizontal screen
size will also change.
PHASE. Minimizes any horizontal distortion and
clear or sharpen the displayed characters.
RGB
75
99
BRIGHTNESS / CONTRAST
RGB
COLOR
PRESET 9300K 6500K
RED
GREEN
BLUE
GAMMA
POSITION
RGB
50
50
TRACKING
RGB
CLOCK
PHASE
