Front Panel Controls
Figure 2-15 Monitor Front Panel Controls
Table 2-1 Monitor Front Panel Controls
Control Function
1 Menu Opens the On-Screen Display (OSD) menu, selects items within the OSD
menu, and closes the OSD menu.
2 – (Minus) If the OSD menu is on, press to navigate backward through the OSD
menu and decrease adjustment levels.
If the OSD menu is inactive, press to open the OSD volume control menu
and adjust the volume level.
3 + (Plus) If the OSD menu is on, press to navigate forward through the OSD menu
and increase adjustment levels.
If the OSD menu is inactive and the monitor is in Net mode, press to open
the OSD volume control menu and adjust the volume level.
If the OSD menu is inactive and the monitor is in PC mode, press to
activate the auto adjustment feature to optimize the screen image.
4 Mode Toggles the monitor between Net mode and PC mode.
5 Power Turns the monitor on or off.
6 Power LED Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
12 Chapter 2 Setting Up the Monitor ENWW
