Component Description
(3) HP TrueVision HD Webcam Records video, captures still photographs, allows
you to video conference and chat online using
streaming video.
To use the webcam, select Start > All Programs >
Communication and Chat > CyberLink YouCam.
(4) Integrated subwoofer Provides superior bass sound.
(5)
USB 2.0 port Connects an optional USB device.
NOTE: For details about different types of USB
ports, see
Using a USB device on page 49.
(6)
USB 3.0 ports (3) Connect optional USB 3.0 devices and provide
enhanced USB power performance.
(7) Optical drive Reads and writes (select models only) to an optical
disc.
(8) b key Enables or disables Beats Audio when pressed in
combination with the fn key.
Beats Audio is an enhanced audio profile that
provides a deep, controlled bass while maintaining a
clear sound. Beats Audio is enabled by default.
You can view and control the bass settings through
the Windows operating system. To view and control
the bass properties:
Select Start > Control Panel > Hardware and
Sound > Beats Audio Control Panel.
(9) fn key Enables or disables Beats Audio when pressed in
combination with the b key.
(10)
Audio-out (headphone) jack/Audio-in
(microphone) jack
Produces sound when connected to optional
powered stereo speakers, headphones, earbuds, a
headset, or television audio. Also connects an
optional headset microphone. The jack does not
support optional microphone-only devices.
WARNING! To reduce the risk of personal injury,
adjust the volume before putting on headphones,
earbuds, or a headset. For additional safety
information, refer to the Regulatory, Safety, and
Environmental Notices.
NOTE: When a device is connected to the jack,
the computer speakers are disabled.
(11)
HDMI port Connects an optional video or audio device, such as
a high-definition television, any compatible digital or
audio component, or a high-speed HDMI device.
(12)
External monitor port Connects an external VGA monitor or projector.
(13) Speakers (2) Produce sound.
24 Chapter 4 Enjoying entertainment features
