Power connector cable
Description Spare part number
Power connector cable 689678-001
Before removing the power connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 36), and then remove the following components:
●
Memory module/wireless module compartment cover (see
WLAN module on page 45)
●
Hard drive (see
Hard drive on page 49)
●
Keyboard (see
Keyboard on page 54)
●
Top cover (see
Top cover on page 57)
To remove the power connector cable:
1. Position the computer upright with the right side toward you.
2. Disconnect the power connector cable (1) from the system board.
3. Release the power connector cable from the clips (2) built into the base enclosure.
ENWW Component replacement procedures 69
