System Unit
System UnitSystem Unit
System Unit
Dimensions
DimensionsDimensions
Dimensions
(H x W x D)
10.4-inch TFT panel display
10.8 x 8.5 x 0.8 in (27.4 x 21.6 x 2.0 cm)
Weight
WeightWeight
Weight
Approximate
3.1 lb (1.4 kg) Tablet PC only
4 lb (1.8 kg) Tablet PC with keyboard
Stand-Alone Power
Stand-Alone PowerStand-Alone Power
Stand-Alone Power
Requirements
RequirementsRequirements
Requirements
Nominal Operating Voltage
14.8 VDC
Peak Operating Power
40 W
Temperature
TemperatureTemperature
Temperature
Operating
50° to 95° F (10° to 35° C)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
Operating
10% to 90% relative humidity, non-condensing
Non-operating
5% to 90% relative humidity, 101.6° F (38.7° C)
maximum wet bulb temperature
Shock
ShockShock
Shock
Operating
10 G, 11 ms, half-sine
Non-operating
60 G, 11 ms, half-sine
Vibration
VibrationVibration
Vibration
Operating
0.5 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate
Non-operating
1.0 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate
Maximum Altitude
Maximum AltitudeMaximum Altitude
Maximum Altitude
(unpressurized)
Operating
0 to 10,000 ft (3,048 m), (14.7 to 10.1 psia)
Non-operating
0 to 30,000 ft (9,144 m), (14.7 to 4.4 psia)
10.4-Inch Colour TFT
10.4-Inch Colour TFT10.4-Inch Colour TFT
10.4-Inch Colour TFT
XGA Display
XGA DisplayXGA Display
XGA Display
Dimensions
DimensionsDimensions
Dimensions
(H x W)
9.29 x 6.82 in (23.6 x 17.3 cm)
Diagonal Size
Diagonal SizeDiagonal Size
Diagonal Size
10.4 in (26.41 cm)
Mounting
MountingMounting
Mounting
Internal Panel Supports, Flange Mounted
Number of Colours
Number of ColoursNumber of Colours
Number of Colours
Up to 16.8M
Contrast Ratio
Contrast RatioContrast Ratio
Contrast Ratio
150:1
Brightness
BrightnessBrightness
Brightness
140 nits typical
Pixel Resolution
Pixel ResolutionPixel Resolution
Pixel Resolution
Pitch
0.264 x 0.264 mm
Format
1024 x 768
Configuration
RGB stripe
Backlight
BacklightBacklight
Backlight
Edge Lit
Character Display
Character DisplayCharacter Display
Character Display
80 x 25
Wide Viewing Angle
Wide Viewing AngleWide Viewing Angle
Wide Viewing Angle
100 degrees with Celeron SKUs
160 degrees with Pentium M SKU DQ871A#ABA
Memory
MemoryMemory
Memory
(optional)
Slot 1
Slot 1Slot 1
Slot 1
(Factory and HP authorized
service provider configurable
only)
256-MB 266-MHz DDR
Standard with Celeron SKUs (may also use 333 MHz)
256-MB 333-MHz DDR
512-MB 333-MHz DDR
Standard with Pentium SKUs
1-GB 333-MHz DDR
Slot 2
Slot 2Slot 2
Slot 2
(available)
256-MB 333-MHz DDR
512-MB 333-MHz DDR
1-GB 333-MHz DDR
External AC Adapter
External AC AdapterExternal AC Adapter
External AC Adapter
Weight
WeightWeight
Weight
0.62 lb (0.28 kg)
Power Supply
Power SupplyPower Supply
Power Supply
(Input)
Operating Voltage
90 to 260 VAC RMS
Operating Current
1.7 A RMS
Operating Frequency Range
47 to 63 Hz AC
QuickSpecs
HP Compaq Tablet PC TC1100
HP Compaq Tablet PC TC1100HP Compaq Tablet PC TC1100
HP Compaq Tablet PC TC1100
Technical Specifications
DA - 11755 Canada — Version 23 — November 2, 2004
Page 12
