Removing the rails 24
Removing the rails
Removing the HP 1U Adjustable Toolless Rails
1. Remove the HP TFT7210R.
2. Remove the brace rail assembly.
3. Locate the spring release.
4. Place your hand on the outside of the HP 1U Adjustable Toolless Rail so that you can move the
spring release.
5. Gently move the spring release toward the inside of the rack (1) while moving the HP 1U Adjustable
Toolless Rail out toward you and away from the rack (2).
NOTE: If you cannot gain access to the spring release from the outside of the HP 1U
Adjustable Toolless Rail, a tool might be required to unlock the spring release from the unit side
of the HP 1U Adjustable Toolless Rail.
6. Repeat the previous steps for the other HP 1U Adjustable Toolless Rail.
