IOGear Q11247-a Laptop Docking Station User Manual



2
Software Installation
Windows® (XP/Vista®/7/8)
1. Before connecting the USB 3.0 Universal
Docking Station, install drivers using the
provided CD.
NOTE: If your PC does not have a CD drive, go
to the link below to download the latest drivers.
www.displaylink.com/support/downloads.php
2. Select Drivers for Windows and then
double click the Setup.exe to launch the
Installation Wizard.
3. Follow the on-screen instructions until the
installation is complete. Restart the
computer when prompted.
Mac OS X (10.6 or later)
1. Before connecting the USB 3.0 Universal
Docking Station, install drivers using the
provided CD.
NOTE: If your Mac does not have a CD drive, go
to the link below to download the latest drivers.
www.displaylink.com/support/mac_downloads.php
3. Follow the on-screen instructions
until the installation is complete.
Restart the computer when
prompted.
2. Double click the DisplayLink.dmg,
then double click the DisplayLink
Software Installer.pkg to launch the
software installer.
