Convenient Functions
[
25%-400% Wide Zoom
]
The bizhub 210 has a wide zoom range of 25%-400% of the
original document. The zoom can be set in 1% increments,
allowing you to make precise size adjustments. Moreover, the
magnification rate can be set independently in both vertical and
horizontal directions.
[
2-in-1 / 4-in-1 Copy
]
*
2
The 2-in-1 / 4-in-1 copy function outputs either two or four pages
onto a single page, allowing you to cut costs by reducing the
amount of paper used.
[
Multi-Access
]
Because the scanning, printing, and communication functions
are completely independent, documents can be faxed even
while other documents are being printed.
[
Shift Sorting/Crisscross Sorting
]
*
2
*
4
*
5
These versatile sorting functions
store the images of multiple
documents temporarily into
memory, then copy or print them
into sets with the pages in correct
order, thereby eliminating the
need for an additional sorter.
Upper Tray
(Print/Fax)
Bottom Tray
(Copy)
[Job Separator]
*
7
Printer/fax outputs and copier outputs are automatically
sorted on separate trays to avoid mix-ups and for easier retrieval.
[Multi-Purpose Cassette & Multi Bypass Tray]
*
6
The Multi-Purpose Cassette accommodates paper from A3 to A5
in size, as well as postcards, transparencies, envelopes, and
other special media. The 100-sheet Multi Bypass Tray also
accepts a variety of media, including
thick paper, transparencies, labels,
and envelopes.
[Maximum Paper Feed Capacity]
The bizhub 210 comes with a standard paper feed capacity of 250
sheets. With optional units, consecutive feeding of up to 1,350
sheets can be achieved, minimising downtime for paper
replenishment and facilitating large copy runs.
[Various Automatic Functions]
The bizhub 210 is equipped with automatic functions that
assure top-quality results. These include auto-density adjustment,
auto-paper selection, and auto zoom setting.
[Double-Sided Copies]
*
3
Double-sided copies can be made from single or double-sided
documents. You can also make double-sided 2-in-1 and 4-in-1
copies. When copying double-sided documents, use the Reverse
Automatic Document Feeder.
[90
O
Image Rotation ]
When the directions of the original and the paper supply are
different, the image is automatically rotated before it is output
to prevent copy mistakes.
Rotates according to
paper supply direction
Original direction
Shift sorting Crisscross sorting
*
1 A4 Crosswise
*
2 The optional Automatic Document Feeder is not required.
*
3 The
optional Automatic Duplex Unit AD-504 is required.
*
4 For Shift Sorting, the optional Shift Tray SF-501 is required.
*
5
T
he optional Paper Feed Unit PF-502 or Multi Bypass Tray MB-501 is required for crisscross sorting.
Also, A4 or B5 output paper must be set in both crosswise and lengthwise directions in the Multi-
Purpose Cassette and either the Paper Feed Unit PF-502 or the Multi Bypass Tray MB-501.
*
6 The Multi Bypass Tray cannot be used to feed sheets for faxing.
*
7
Requires the optional Job Separator JS-503.
[Quick Warm-Up/Fast First Copy]
The bizhub 210 delivers the first copy in 7 seconds
*
1
or less,
and when in the energy saving, stand-by mode, it’s ready to go
in 15 seconds or less. This eliminates waiting time so you can
be more productive.
A lamp, which accompanies the
Job Separator and is located on the
front of the main body, will switch
on when the Printer/Fax tray
moves up, alerting the user that
there are documents on the tray.
5
