2. Select Network Printer and click Next to see the Locate your Printer screen,
as shown in Figure 8-4.
3. Select Connect to a printer on the Internet or on your intranet, and enter
the URL of the IPP Server as follows, where ip_address represents the IP
Address of the IPP Server, and 631 is the port number.
Parallel Port 1 ip_address:631/ipp/P1
4. If the connection can be established, and the printer on that port is online, the
dialog box shown in Figure 8-5 will be displayed. This screen notifies you
that the printer driver is not installed. Click the OK button.
38
Wireless PrintServer
Figure 8-4
Figure 8-5
Note: These entries are case sensitive. They must be entered as shown,
with “ipp” in lowercase, and “P1” in UPPERcase.
37
3. Click the Port Settings or Configure Port button (Details or Port tab,
depending on your version of Windows). The Configure IPP Port screen
(shown in Figure 8-3) will appear.
There are two settings—Retry Interval and Retry Count—which can be
adjusted if you have problems connecting to the IPP Server.
· Retry Interval sets the time interval (in seconds) between connection
attempts. Increase this number if you have a poor connection, or the
remote server is very busy.
· Retry Count sets how many connection attempts will be made. Increase
this number if you have a poor connection, or the remote server is very
busy.
IPP Client Setup for Windows 2000 and XP
Windows 2000 and XP have their own IPP Client, and there is no need to install
the supplied IPP Client Software. To use this IPP Client with the Wireless
PrintServer, follow this procedure:
1. Start the Add Printer wizard.
Instant Wireless™ Series
Figure 8-3
