28
MODEL CPE 1000
CPE 1000i
CPE 2000
CPE 2000i
CPE 3000
CPE 3000i
PROTECTION
Overload 100%~120% delay 60-seconds before switching to
Bypass Mode.
120%~150% delay 10-seconds before switching to
Bypass Mode.
>150% immediately switches to Bypass Mode.
Short-Circuit a) Inverter Mode: UPS shuts down.
b) Bypass Mode: AC Input fuse opens.
Overheat a) Utility Normal: Switch to Bypass Mode.
b) Utility Abnormal: Alarm sounds continuously,
Fault LED illuminates then the output turns off.
Brownout, Blackout,
Overvoltage
Switches to the Battery Mode.
Battery Low Alarm continuous, until Low Battery Cut-Off
Noise Suppression Comply with EN50091-2.
Spike Suppression Comply with EN61000-4-5.
ALARM
Audible and Visual Line Failure, Battery Low, Bypass, Overload, Fault.
PHYSICAL
Dimensions Net
(WxHxD)
5.8x8.78x15.8 inch
(147x223x401 mm)
5.1x14.4x18.9 inch
(130x365x479 mm)
7.5x14.4x17.8 inch
(190x365x453 mm)
Weight Net
33.1 Lbs
15 Kgs
59.5 Lbs
27 Kgs
79.4 Lbs
36 Kgs
Dimensions
Shipping
(WxHxD)
12.2x15.35x22.1 inch
(310x390x560 mm)
11.4x20.1x24.8 inch
(290x510x630 mm)
13.4x24.8x24.1 inch
(340x630x610 mm)
Weight Shipping
40 Lbs
18 Kgs
71 Lbs
32 Kgs
84 Lbs
38 Kgs
ENVIRONMENT
Operating Temp
0 to 40°C (+32 to +104°F)
Storage Temp
-15 to +45°C (+5 to +113°F)
Operating/Storage
Humidity
30 to 90% Non-Condensing
Operating Elevation 0 to 3,000m (0 to +10,000 ft)
Storage Elevation 0 to 15,000m (0 to +50,000 ft)
Audible Noise <45 dBA at 1 meter (3 ft)
SAFETY CONFORMANCE
Safety Standard EN50091-1, UL1778, CSA 22.2 (cUL)
EMC Standard EN50091-2, EN61000-3-3, EN61000-3-2,
FCC Class A
Marks CE, cUL
Specifications are subject to change without prior notice.
29
A.2. Obtaining Service
If the UPS requires Service:
1.Use the TROUBLESHOOTING section to eliminate obvious causes.
2.Verify there are no circuit breakers tripped. A tripped circuit breaker is
the most common problem.
3.Call your dealer for assistance. If you cannot reach your dealer, or if they
cannot resolve the problem call or fax MINUTEMAN Technical Support at
the following numbers; Voice phone (972) 446-7363, FAX line (972) 446-
9011 or visit our Web site at www.minutemanups.com the "Discussion
Board". Please have the following information available BEFORE calling
the Technical Support Department.
A. Your name and address.
B. Where and when the unit was purchased.
C. All of the model information about your UPS.
D. Any information on the failure, including LEDs that may be illuminated.
E. A description of the protected equipment, including model numbers if
possible.
F. A technician will ask you for the above information and, if possible, help
solve your problem over the phone. In the event that the unit requires
factory service, the technician will issue you a Return Material Authorization
Number (RMA #).
G. If the UPS is under warranty, the repairs will be done at no charge. If
not, there will be a charge for repair.
4. Pack the UPS in its original packaging. If the original packaging is no
longer available, ask the Technical Support Technician about obtaining a
new set. It is important to pack the UPS properly in order to avoid damage
in transit. Never use Styrofoam beads for a packing material.
A. Include a letter with your name, address, daytime phone number, RMA
number, a copy of your original sales receipt, and a brief description of the
problem.
5. Mark the RMA # on the outside of all packages. The factory cannot
accept any package without the RMA # marked on the outside.
6. Return the UPS by insured, prepaid carrier to:
Para Systems Inc.
MINUTEMAN UPS
1455 LeMay Drive
Carrollton, TX 75007
ATTN: RMA # _______
