Chapter 2 – Installation
Multi-Tech Systems, Inc. MT5634ZBA-Series User Guide (S000286G) 9
Step 2: Connect the Modem to Your PC
Turn off your computer. Place the modem in a convenient location, and then connect it to your computer’s serial port, the
telephone line or leased line, AC power, and, optionally, your telephone.
Global Connections
Connections - No Voice
Connections With Voice
Non-Global Connection
PWR RS232 PHONE LINE
