Specifications
17 inches (16.0 inches viewable)
90 degree deflection
0.25mm dot pitch
AGARAS (Anti-Glare Anti-Reflective Anti-Static) coating
Horizontal Freq. 30 - 71kHz (Automatic)
Vertical Freq. 55 - 120Hz (Automatic)
Input Form Separate TTL, Positive/Negative
Signal Input 15 pin D-Sub Connector
Input Form
Separate, RGB Analog, 0.7Vp-p/75 ohm, Positive
DDC 2B
Normal
73W
Stand-by/Suspend
≤ 15W
DPM Off ≤ 5W
640 x 480 @ 60Hz to 120Hz
800 x 600 @ 55Hz to 110Hz
832 x 624 @ 55Hz to 106Hz
1024 x 768 @ 55Hz to 87Hz
1152 x 870 @ 55Hz to 77Hz
1280 x 1024 @ 55Hz to 60Hz
Max VESA 1280 x 1024 @ 60Hz
Recommend VESA 1024 x 768 @ 85Hz
Width 400 mm / 15.7 inches
Height 404mm / 15.9 inches
Depth 429 mm / 16.9 inches
Net 15.5 kg / 34.1 lbs
AC 100-240V~ 50/60Hz
2.0A @ 100-240V
Operating Conditions
Temperature 0˚C to 35 ˚C
Humidity 30 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 10 % to 90 % non-Condensing
Detached
Attached
Detached
Picture Tube
Sync Input
Video Input
Plug & Play
Power
Consumption
Resolutions
Dimensions
&Weight
(with tilt/swivel
stand)
Power Input
Current Rating
Environmental
Conditions
Tilt/Swivel Stand
Signal cable
Power cord
NOTE:
Information in this document is subject to change without notice.
