A ROTATE (raster rotation): Rotates the entire display clockwise or
counter clockwise.
x Color Control
Two color presets select the desired color setting. Each color setting is
adjusted at the factory to the stated Kelvin.
RED, GREEN, BLUE: Decreases or increases red, green, or blue
depending upon which is selected. The change in color will
appear on screen and the direction (decrease or increase) will be
shown by the bars.
? Tools
y DEGAUSS: Eliminates the buildup of stray magnetic fields which
alter the correct scan of the electron beams and affect the purity
of the screen colours, focus, and convergence. When activated,
your screen image will jump and waver a bit as the screen is
demagnetized.
Caution: Please allow a minimum of 20 minutes to elapse
between uses of the Degauss function.
= IPM System OFF MODE:
ON:
The IPM System works normally, all
stages of the energy saving are
used.
OFF:
The OFF MODE of the IPM System is
not used.
NOTE: For standard computers and display cards you should
keep the factory setting ON.
@ ALL RESET: Selecting ALL RESET allows you to reset all OSM control
settings back to the factory settings except IPM System. Individual
settings can be reset by highlighting the control to be reset and
pressing the RESET button.
z Information
Indicates the frequency setting, model and serial number of your
monitor.
E-5
