English-9
BRIGHTNESS
Adjusts the overall image and background screen brightness.
To enter ECO MODE, press the “1 2/RESET” button.
ECO MODE OFF: Sets brightness variable to 100%
ECO MODE1: Sets brightness to 80%.
This setting can adjust brightness to a range in which power is reduced to meet Energy Star measurement conditions.
ECO MODE2: Sets brightness to 30%.
This setting can adjust brightness to a range in which power is reduced by 30% compared to the maximum brightness setting.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST
Adjusts the image displayed for non-standard video inputs. (Analog input only)
AUTO ADJUST
Automatically adjusts the Image Position, the H. Size and Fine setting. (Analog input only)
LEFT/RIGHT
Controls Horizontal Image Position within the display area of the LCD. (Analog input only)
DOWN/UP
Controls Vertical Image Position within the display area of the LCD. (Analog input only)
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting. (Analog input only)
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting. (Analog input only)
COLOR CONTROL SYSTEMS
Five color presets (9300/7500/sRGB/USER/NATIVE) select the desired color setting.
COLOR RED
Increase or decreases Red. The change will appear on screen.
COLOR GREEN
Increase or decreases Green. The change will appear on screen.
COLOR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSD control settings back to the factory settings. The 1 2/RESET
button will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting
the control to be reset and pressing the 1 2/RESET button.
EXIT
Selecting EXIT allows you exit OSD menu/ sub menu.
LANGUAGE
OSD control menus are available in nine languages.
