English-12
Specifications
Monitor Specifications AccuSync AS191 Monitor Notes
LCD Module Diagonal: 48.3 cm/19.0 inches Active matrix, thin film transistor (TFT)
Viewable Image Size: 48.3 cm/19.0 inches liquid crystal display (LCD); 0.294 mm dot
Native Resolution (Pixel Count): 1280 x 1024 pitch; 250 cd/m
2
white luminance, 900:1
contrast ratio, typical.
Input Signal 15pin Mini D-sub: Analog RGB 0.7 Vp-p/75 ohms
Sync
Separate sync. TTL level (Positive/Negative)
DVI-D Digital RGB DVI(HDCP)
Display Colors Analog input: 16.7 M Depends on display card used.
Viewing Angle Left/Right: -80°/+80° (CR>10)
Up/Down: -80°/+80° (CR>10)
Synchronization Range Horizontal: 31.5 kHz to 81.1 kHz Automatically
Vertical: 56 Hz to 76 Hz Automatically
Resolutions Supported Landscape: 720 x 400*
1
: VGA text Some systems may not support all
640 x 480*
1
at 60 Hz to 75 Hz modes listed.
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 75 Hz
1152 x 864*
1
at 75 Hz
1152 x 870*
1
at 75 Hz
1280 x 960*
1
at 60 Hz to 75 Hz Recommended resolution is 60 Hz for
1280 x 1024 at 60 Hz to 75 Hz.....................optimal display performance.
Active Display Area Horizontal: 376 mm
Vertical: 301 mm
Power Supply 100 - 240 V ~ 50/60 Hz
Current Rating 0.5 - 0.3 A
Power Maximun Operation: 24 W
Consumption Normal Operation: 20 W
Dimensions Landscape: 412.5 mm (W) x 403.1 mm (H) x 205.1 mm (D)
16.2 inches (W) x 15.9 inches (H) x 8.1 inches (D)
Weight 4.4 kg (9.7 lbs)
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 20% to 80%
Altitude: 0 to 2,000 m/0 to 6,562 Feet
Storage Temperature: -10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 12,192 m/0 to 40,000 Feet
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
