Specifications
11
Monitor MultiSync
®
FP955
™
Notes
Specifications Monitor
Picture Tube Diagonal: 50 cm/19 inch 90° deflection, 0.24 grille pitch,
Viewable Image Size: 458 mm/18 inch medium short persistence phosphor,
Radius: 50,000 mm aperture grille CRT, multi-layered,
anti-static screen coating, semi-dark-tint
screen, and OptiClear
®
screen surface.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync
(Negative) 0.3 Vp-p
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 30 kHz to 110 kHz Automatically
Range Vertical: 50 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 50 to 160 Hz
Some systems may not support
Resolution based on
horizontal and
800 x 600 @ 50 to 160 Hz
all modes listed.
vertical frequencies only
832 X 624 @ 50 to 160Hz
1024 x 768 @ 50 to 132 Hz
1152 x 870 @ 50 to 118 Hz
1280 x 1024 @ 50 to 101 Hz ...................
NEC-Mitsubishi Electronic Display cites
1600 x 1200 @ 50 to 87 Hz
recommended resolution at 85 Hz for
1792 x 1344 @ 50 to 78 Hz
optimal display performance.
1800 x 1440 @ 50 to 73 Hz
1856 x 1392 @ 50 to 75 Hz
1920 x 1440 @ 50 to 73 Hz
Active Display Area Horizontal:
356 mm/14.0 inches Dependent upon signal timing used,
(Factory Setting) Vertical:
267 mm/10.5 inches and does not
include border area.
Active Display Area
366 mm/14.4 inches Dependent upon signal timing used,
(Full Scan)
275 mm/10.8 inches and does not
include border area.
Power Supply
AC 100 – 120 V/220 - 240 V, 50/60 Hz
Current Rating 1.8A @ 100
–
120 V / 0.9A@ 220-240 V
Dimensions
442 mm (W) x 468.3 mm (H) x 448.6 mm (D)
17.4 inches (W) x 18.4 inches (H) x 17.7 inches (D)
Weight 24 kg
52.9 lbs
Environmental Considerations
Operating Temperature: +10°C to +35°C/+50°F to +95°F
Humidity: 30% to 80%
Altitude: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C/-4°F to +140°F
Humidity: 10% to 90%
Altitude: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
