Quick Start
To attach your MultiSync
®
LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable
to the connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync Macintosh
cable adapter to the computer
(Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to
the MultiSync Macintosh cable adapter (Figure B.1). Tighten all screws.
NOTE: To obtain the MultiSync Macintosh cable adapter, call NEC Technologies
at (800) 820-1230.
3. Connect the 15-pin mini D-SUB of the video signal cable and the AC Adapter cable.
Place the AC Adapter cable under Clip A (Figure C.1).
NOTE: Incorrect cable connections may result in irregular operation, damage
display quality/components of LCD module and/or shorten the module’s life.
4. Connect one end of the power cord to the AC Adapter and the other end to the power
outlet (Figure D.1).
5. Turn on the monitor (Figure E.1) and the computer.
6.
To complete the setup of your MultiSync LCD monitor:
A. Set the resolution to 1024 x768 @ 75 Hz.
NOTE: For download information on the Windows
®
95/98 INF file for your MultiSync
LCD monitor, refer to the References section of this User’s Manual.
B. Use the following OSM
™
controls:
• Auto Adjust Contrast
• Auto Adjust
NOTE: Manual adjustment of the H/V Position and Image Adjust H. Size/Fine
controls may be required to complete setup of your MultiSync monitor.
For a full description of these OSM controls, refer to the Controls section of
this User’s Manual.
7. Refer to User’s Manual in the LCD Setup Software CD case for installation and operation
of this software.
NOTE: If you have any problems, please refer to the Troubleshooting section of
this User’s Manual.
3
