Problem Check These Items
Display image is not centered, too
smaIl, or too large
Use the OSM Size and Position
controls to adjust the image.
Color looks blotchy Adjust the Brightness, then Contrast
Controls. Access the Degauss Control
through OSM. Activate the Degauss
Control. CAUTION: A minimum
interval of 20 minutes should exist
before the Degauss Control is used a
second time.
No green color (if using BNC
connection)
Check the BNC cables for proper
connection (G and CS connection
may be reversed).
Specifications
Picture Tube 53 cm (21 inch) aperture grille CRT, 49.8 cm (19.6 inch)
viewable image size, 0.28 mm horizontal pitch,
Medium-Short persistence phosphor, multi-layered,
anti-static OptiClear coating
Input Signal Video Analog 0.7 Vp-p 75 Ω Positive
Sync Separate sync.
Horizontal sync.
Vertical sync.
Composite sync.
TTL Level
Positive/Negative
Positive/Negative
TTL Level
Positive/Negative
Display Colours Analog Input: Unlimited colours
(Depends on the graphics board)
Synchronisation
Range
Horizontal 31 kHz to 94 kHz (Automatically)
Vertical 55 Hz to 160 Hz (Automatically)
Resolutions Maximum 1600 x 1200 (75 Hz non interlaced)**
Recommended 1280 x 1024 (85 Hz non interlaced)*
Specifications E - 21
