NEC Versa M540/PB EasyNote R7 Disassembly Manual
Page 8
Removing the Memory Module
To remove the Memory Module, first remove the Battery (see Removing the Battery) then
perform the following steps:
1. Release the screws retaining the memory module slot cover.
Fig. 7 Removing the screw retaining the memory module slot cover
2. Unclip the memory module as shown in Fig. 8
Fig. 8 Removing the memory module
3. Remove the memory module from its slot and put it aside.
M2x3.5 Black
