5
Table 3. 10/100BASE-TX MDA
Item Label Description
1
100 100BASE-TX port status LEDs
(g
reen
)
:
On: The correspondin
g
port is set to
operate at 100 Mb/s.
Off: The link connection is bad or there is
no connection to this port.
Blinkin
g
: The correspondin
g
port is
mana
g
ement disabled.
2 10 10BASE-T port status LEDs (green):
On: The corresponding port is set to
operate at 10 Mb/s.
Off: The link connection is bad or there is
no connection to this port.
Blinking: The corresponding port is
management disabled.
3 F Dx Full-duplex port status LEDs (green):
On: The corresponding port is in
full-duplex mode.
Off: The corresponding port is in
half-duplex mode.
(continued)
302403-C.mkr Page 5 Monday, May 24, 1999 4:30 PM
