REMOTE SENSOR (THN122N)
This product is shipped with two THN122N Thermometer
Sensors that collect temperature data. Data can be collected
from up to 3 sensors. Additional sensors sold separately.
SETUP SENSOR
1. Open the remote sensor battery compartment with
a small Phillips screwdriver.
2. Insert the batteries, matching the polarity (+ and –)
as shown in the battery compartment.
3. Set the channel. The switch is located in the battery
compartment.
4.
Place the sensor near the main unit. Press RESET on
the sensor. Then, press and hold MEMORY and
CHANNEL on the main unit to initiate signal sending
between the sensor and the main unit. The reception
icon on the main unit will blink for approximately 3
minutes while it is searching for the sensor. (Refer to
the “Data Transmission” section for more information.)
5. Close the remote sensor battery compartment.
6. Secure the sensor in the desired location using the
wall mount or table stand.
Installing the batteries:
SWITCH OPTION
Channel Channel 1-3. If you are using more than
one sensor, select a different channel
for each sensor.
For best results:
• Insert the batteries and select the channel before
you mount the sensor.
• Place the sensor out of direct sunlight and moisture.
• Do not place the sensor more than 230 feet (70
meters) from the main (indoor) unit.
• Position the sensor so that it faces the main (indoor)
unit, minimizing obstructions such as doors, walls,
and furniture.
• Place the sensor in a location with a clear view to
the sky, away from metallic or electronic objects.
• Position the sensor close to the main unit during
cold winter months as below-freezing temperatures
may affect battery performance and signal
transmission.
You may need to experiment with various locations to
get the best results.
