BACK VIEW
TABLE STAND
The wall clock can be placed on a table using the table
stand.
1. Rotary Motion Sensor
z Detects motion and activates the nightlight and
clock backlight in accordance with the
settings used.
z Twist the knob to direct the sensor to the position
you want.
2. Light Sensor
z Detects the light intensity of the environment.
3. Light ON
z Press to turn the clock backlight ON for 10
seconds remotely.
4. Power - ON / OFF
z Slide to the appropriate setting to turn the battery
or AC power ON or OFF.
5. 4.5V Adaptor Socket
6. Light Panel
z When activated the panel will light up.
7. LED Indicator
1. Wall Mount Hole
2. Battery Compartment
z Uses 3 x UM-3 / AA 1.5V batteries.
3. Channel 1 / 2
z Slide to select either Channel 1 or Channel 2.
4. Code switch
z Slide to change the Code.
5. Mode - On / Off / Auto
z Slide switch to ON - the nightlight will turn on in
a dark room.
z Slide switch to OFF - the nightlight is turned
off.
z Slide switch to AUTO - the nightlight will only be
activated by motion in a dark room.
6. Clock Control - On / Off
z Slide switch to ON - when motion is detected,
the clock backlight will be activated.
z Slide switch to OFF - the clock backlight will not
be activated by the motion sensor.
7. + Light - Rotary knob
z Rotate to adjust the sensitivity of the light
sensor.
8. Reset button
z Press to reset the nightlight.
KEY FEATURES - NIGHTLIGHT WITH
MOTION SENSOR
FRONT VIEW
