K 531 DFKE0655YA-0 COVER, HINGE

1

K 532 DFKE0657ZA COVER, KB CABLE

1

K 533 DFKE0658ZB-4 COVER, HDD/BAT

1

K 534 DFHR3181ZA PACKING, HDD/BATT COVER

1

K 535 DFHR3278ZA CORE HOLDER, RJ11

1

K 538 DFHR7968ZA SHEET, CDD 1

K 540 DFHE0489ZB CUSHION, HDD

1

K 541 DFHP7106YA TAPE, KEYBOARD

1

K 542 DFQT9675ZA LABEL, ENERGY STAR

1

K 543 DFQT9821ZA LABEL, MODEM

1

K 544 DFJE10T032BS FFC, IrDA

1

K 545 DFMC0724ZA SHEET, CONDUCTIVE, HDD

1

K 546 DFMX0921ZA SHEET, INSULATION, RJ11

1

K 547 DFMX1063ZA SHEET, INSULATION, IrDA

1

K 548 DFMX1000ZA SHEET, CONDUCTIVE, CPU

1

K 549 DFWV82A0127 ASS'Y, MP COVER

1

K 550 DFWV82A0128 ASS'Y, CONNECTOR COVER

1

K 551 DFWV82A0129 ASS'Y, PC CARD COVER

1

K 552 DFHR3203ZA SHEET, LCD SPACER 2

K 553 DFHG1568ZA DAMPER, LCD HINGE 2

K 2 DFBE0010YA-0 RING, POWER SW

1

K 3 DFGL0096XA-0 LENS (A), LED

1

K 4 DFGL0097ZB-0 LENS (B), LED

1

K 5 DFGX0293ZA-0 COVER PLATE, LAN

1

K 6 DFGX0289XA-0 COVER, PALM TOP, MID

1

K 7 DFGX0290ZA-0 COVER, PALM TOP, L

1

K 8 DFGX0291ZA-0 COVER, PALM TOP, R

1

K 9 DXQT2+D25VL SCREW

10

K 10 DXSB26+5VL SCREW

24

K 11 DFHE5058ZA SCREW

6

K 13 DXSB26+6VL SCREW

8

K 14 DFHE5104YA SCREW

9

K 16 DFHG1407YA PACKING, WATERPROOF, RJ11

1

K 17 DFHG1423XA-0 COVER, SERIAL PORT

1

K 18 DFHG1424WB-0 COVER, USB PORT

1

K 19 DFHG1433YA CUSHION, SPEAKER

1

K 20 DFHG1609ZA-0 COVER, DC-IN

1

K 21 DFHG1463ZA CUSHION, MICROPHONE

1

K 22 DFHG1481ZA PACKING, WATERPROOF, ANTENNA CABLE

1

K 23 DFHG1465ZA PACKING, WATERPROOF, BODY

1

K 25 DFHG1467ZB CUSHION, LEAD SWITCH

1

K 28 DFHG809ZA RUBBER, LCD STOP

2

K 31 DFHG814ZB PACKING RING, WATERPROOF, POWER SW

1

K 32 DFHG815XA PACKING, WATERPROOF, TOUCH PAD

1

K 40 DFHR7938ZC SHEET, WATERPROOF, MICROPHONE

1

K 42 DFHR7940ZB SHEET, SW COVER, WM

1

K 49 DFKH1011ZA-4 ASS'Y, HANDLE

1

K 50 DFMC0406XA GASKET, MP

1

K 52 DFMD1144YA ANGLE, LOCK STOPPER

1

K 53 DFMD1145YA ANGLE, PCMCIA

1

K 54 DFMD4032ZA PLATE, COVER, SERIAL PORT

1

K 55 DFMD4033ZA PLATE, COVER, DC-IN/USB PORT

2

K 57 DFMD7745ZA ANGLE, MODEM CONNECTOR

1

K 58 DFMD7747ZA ANGLE-A, HEAT PIPE

1

K 59 DFMD7748ZA ANGLE-B, HEAT PIPE

1

K 60 DFMD7749ZB ANGLE, LOCK BACK

1

K 62 DFMD7753WA HOLDER, LED LENS

1

K 63 DFMD7756YA ANGLE-A, BATTERY HOOK

1

K 64 DFMD7757YA ANGLE-B, BATTERY HOOK

2

K 67 DFMX0900ZA SHEET, INSULATING

1

K 68 DFMX0903ZA TAPE

2

K 71 DFMY0276YA RUBBER, HEAT PIPE

1

K 73 DFMY9014ZC HEAT PIPE

1

K 76 DFUS0279ZA GROUND BOARD SPRING-A

1

K 77 DFUS0280ZA GROUND BOARD SPRING-B

1

K 82 DFUW0109ZA SPRING, POWER SWITCH

1
