Replacement Parts List Comparison Table
CF-28SRJ05KM
Q'TY
CF-28S3JGZKM CF-28SRJ05KM
TS12 PCB
CN852 ------------- K1MN08B00073 CONNECTOR 0->1
CN853 ------------- K1KA04B00137 CONNECTOR 0->1
SENSOR PCB
C12456 ------------- ECUV1C104ZFV CAPACITOR, 16V, 0.1µF0->5
C3 ------------- DCUE1C106MBY CAPACITOR, 16V, 10µF0->1
CN1 ------------- DFJP217ZA006 CONNECTOR 0->1
CN2 ------------- K1KA07A00132 CONNECTOR 0->1
IC1 ------------- B3JB00000007 IC, PHOTO 0->1
IC2 ------------- C0DBZHC00014 IC, REGULATOR 0->1
IC3 ------------- DA7ST08U85L0 IC, CMOS 0->1
Q1 ------------- 2SC4081RT107 TRANSISTOR 0->1
R1 4 ------------- ERJ3GEYJ103V RESISTOR, 1/16W, 10kΩ 0->2
R2 ------------- ERA3YED221V RESISTOR, 1/16W, 220Ω 0->1
R3 ------------- ERA3YED101V RESISTOR, 1/16W, 100Ω 0->1
Note: Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
REF. NO. and
AREA
DESCRIPTIONPART NO.
