Factory Preset Timings
Timing
Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
Sync Polarity
(H/V)
VGA 640 X 350 31.470 70.089 + / -
VGA 720 X 400 31.467 70.082 - / +
VGA 640 X 400 31.469 70.087 - / +
VESA 640 X 480 31.469 59.940 - / -
VESA 640 X 480 37.861 72.809 - / -
VESA 640 X 480 37.500 75.000 - / -
VESA 640 X 480 35.000 66.667 Composite
VESA 800 X 600 35.156 56.250 + / +
VESA 800 X 600 37.879 60.317 + / +
VESA 800 X 600 48.077 72.188 + / +
VESA 800 X 600 46.875 75.000 + / +
VESA 832 X 624 49.715 74.535 Composite
VESA 1024 X 768 48.363 60.004 - / -
VESA 1024 X 768 56.476 70.069 - / -
VESA 1024 X 768 58.036 71.916 - / -
VESA 1024 X 768 60.023 75.029 + / +
VESA 1024 X 768 60.241 74.927 Composite
VESA 1280 X 1024 63.981 60.020 + / +
VESA 1280 X 1024 79.976 75.025 + / +
Power Management System
This monitor matches VESA® DPMS (Display Power Management Standard) Standards.
For the monitor’s power saving features to work, the video board or computer must also
match VESA DPMS standards. The Off state means the monitor is in the lowest DPMS state
with the highest power savings.
