1.4 PRODUCT SPECIFICATION
Model GSW-1602SF GSW-2404SF GSW-2416SF
Hardware Specification
Network ports 16 24 24
SFP/mini-GBIC slot 2 4 16
Switch architecture Store-and-Forward
Switch Fabric 32Gbps 48Gbps
Switch throughput 23.8Mpps 35.7Mpps
Address Table 8K entries
Share data Buffer 340KB 500KB
Flow Control Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex
Dimensions (mm) 440 x 210 x 44 (1U height) 440 x 220 x 44
Weight 2kg 2kg 2.6 kg
Power Requirement 100-240V AC, 50-60 Hz
Power Consumption 30 watts, 102BTU 60 watts, 190BTU
Standards Conformance
Network Standards IEEE 802.3 (Ethernet),
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3z (Gigabit Ethernet, 1000Base-SX/LX)
IEEE 802.1Q (Tagged VLAN)
IEEE 802.1w (Rapid Spanning Tree)
IEEE 802.1X (Port-Based Authentication)
IEEE 802.3ad (Link Aggregation Control Protocol)
IEEE 802.3x (Full-duplex flow control)
Operating Temperature 0~50ºC
Storage Temperature -40~70ºC
Operating Humidity 5% to 90% , relative humidity, non-condensing
Storage Humidity 5% to 90% , relative humidity, non-condensing
Regulation Compliance FCC Part 15 Class A, CE
-3-
