PRINTRONIX T5000 / SL5000 Thermal Printer
Maintenance Plan Summary
PRINTRONIX Confidential Document - Not to be Duplicated.
All prices stated herein are subject to change in accordance with contract terms and conditions
Page 12
Level 3 Spares, T5X04/T5X06/T5X08
(Continued)
Spare Spare Part Part Description List T5X04 T5X06 T5X08
Level Number Price
3 171088-001 Indicator, Head Pressure Dial (Lg Knob) $5.00
√ √ √
3 171087-001 Knob, Lead Screw Lg 1.15” OD $5.00
√ √ √
3 170625-001 Lens, Control Panel $5.00
√ √ √
3 171714-001 Lever, Deck Lock $96.24
√ √ √
3 750659-001 Pad, Rubber $5.00
√ √ √
3 171962-003 Pan, Assy, 4 inch, Phase 2 $100.50
√
3 171962-002 Pan, Assy, 6 inch, Phase 2 $106.50
√
3 171962-001 Pan, Assy, 8 inch, Phase 2 $118.50
√
3 172474-003 Peel/Tear Assy, T5XXX, 4 inch, Phase 2 $221.45
√
3 172474-002 Peel/Tear Assy, T5XXX, 6 inch, Phase 2 $223.75
√
3 172474-001 Peel/Tear Assy, T5XXX, 8 inch, Phase 2 $236.25
√
3 172196-001 Rack, Gimbal Pivot, 6 & 8 inch $67.48
√ √
3 172197-001 Rack, Gimbal Pivot, 4 inch $5.00
√
3 171864-001 Retainer, Head Latch, Inboard $17.71
√
3 171864-002 Retainer, Head Latch, Outboard $16.19
√
3 750892-001 Screen, Fan $10.50
√ √ √
3 171825-001 Shaft, Media Damper 4 .375 $30.60
√
3 750477-001 Shaft, Media Damper 6 & 8 .375 $13.62
√ √
3 172142-001 Shaft, Head Pressure, 4 inch $17.82
√
3 171086-002 Shaft, Head Pressure, 6 inch $17.34
√
3 171086-001 Shaft, Head Pressure, 8 inch $18.66
√
3 171166-001 Shaft, Ribbon Guide, 4 inch $36.30
√
3 170261-002 Shaft, Ribbon Guide, 6 inch $40.80
√
3 170261-001 Shaft, Ribbon Guide, 8 inch $45.00
√
3 203328-001 Socket Strip, 60 pin $15.00
√ √ √
3 170876-001 Spacer, Gimbal $8.76
√ √ √
3 171642-001 Spring Kit,Ribbon Guide, T5 $141.55
√ √ √
3 171146-001 Spring, Leaf (2 required) $6.24
√ √ √
3 750641-001 Spring, Media Damper $5.00
√ √ √
3 203260-001 Spring, Stepper Motor $5.00
√ √ √
3 203433-001 Stud, Ball, 10mm $5.00
√ √ √
3 203479-001 Take-up Core, 6 inch $5.00
√
3 203480-001 Take-up Core, 8 inch $5.00
√
3 203478-001 Take up Core, 4 inch $5.00
√
3 750599-001 Tensioner, Belt $5.00
√ √ √
3 203464-001 Thermal Gap Filler Pad $5.00
√ √ √
