Psion Teklogix CH4000 Quick Reference Guide 7
3.3 Operating The USB Dock
The CH4000 Desktop Docking Station offers a rear-mounted host or
device USB connection to the Ikôn. The Ikôn supports communica-
tion with low- and full-speed USB 1.1 compliant devices and hosts
through the docking station.
The Type A receptacle may be used for ActiveSync
®
among other
applications typical for a Type A port (see Figure 3.1).
Move the sliding door selector to alternate between the Type A and
Type B USB ports.
Figure 3.1 Desktop Docking Station Rear View
Sliding Door Type A USB Port
Type B USB Port Sliding Door
DC Jack
DC Jack
