15
Single item entries
Department entries
For a merchandise classification, the cash register provides a maximum of 99 departments. To the
departments, group attributes such as taxable status are applied to items when they are entered.
• When using the department keys (for department 1 to 40)
For department 1 to 20, enter a unit price and press a department key. If you use a programmed unit price,
press a department key only.
For department 21 to 40, enter a unit price, press the
D
key and press a department key. If you use a
programmed unit price, press the
D
key and press a department key.
*
1
Less than the programmed upper limit amounts
When zero is entered, only the sales quantity is
added.
*
2
For the departments 21 through 40, press the
department shift key.
Please note if you press the same key after using the
D
key, it acts as a repeat entry. For
example, when you register an item of dept. 21 using the
D
key and then an item of dept. 1
using the preset unit price, you should use the department code entry key described below for the
dept. 1 item. If you just press the
¡
key to register dept. 1 item, it will act as a repeat entry of
dept. 21 item.
• When using the department code entry key
Enter a department (dept.) code and press the
d
key, then enter a unit price and press the
d
key again. If
the dept. code is programmed to preset price entry style and a unit price is preset, the cash register will finish
its registration operation.
*
1
Less than the programmed upper limit
amounts
When zero is entered, only the sales
quantity is added.
*
2
After you enter a unit price, you can
press the
q
key instead of the
d
key.
PLU/sub-department entries
For another merchandise classification, the cash register provides a maximum of 7000* PLUs/sub-departments.
PLUs are used to call up preset prices by a code entry. Sub-departments are used to classify merchandise into
smaller groups under the departments. Every PLU and sub-department has a code from 1 to 7000, and should
belong to a department to obtain attributes of that department.
The cash register is pre-programmed to PLU mode and zero for unit price. To use PLU entries, their preset unit
prices should be previously programmed. (Refer to page 38.)
To use sub-department entries, change to sub-department mode for the PLU codes.
*A total of 7000 codes, including UPC codes, can be programmed.
• PLU entries
PLU code
(1 to 7000)
p
Dept. code
(1 to 99)
Unit price *
1
(max. 7 digits)
When using a programmed unit price
(In case only preset price entry is allowed.)
dd
*
2
Department keyUnit price *
1
(max. 7 digits)
When using a programmed unit price
D
*
2
Item Entries
3
