SMC Networks SMCGS24-Smart Switch User Manual



W
EB
C
ONFIGURATION
13
Received Broadcast
Packets
The number of packets, delivered by this sub-layer to
a higher (sub-)layer, which were addressed to a
broadcast address at this sub-layer.
Transmitted Octets The total number of octets transmitted out of the
interface, including framing characters.
Transmitted Unicast
Packets
The total number of packets that higher-level
protocols requested be transmitted to a
subnetwork-unicast address, including those that
were discarded or not sent.
Transmitted Errors The number of outbound packets that could not be
transmitted because of errors.
Received Normal Priority
Packets
The total number of received packets that set as High
Priority in the QoS settings.
Transmitted Normal
Priority Packets
The total number of transmitted packets that set as
High Priority in the QoS settings.
RMON Statistics
Drop Events The total number of events in which packets were
dropped due to lack of resources.
Received Frames The total number of frames (bad, broadcast and
multicast) received.
Multicast Frames The total number of good frames received that were
directed to this multicast address.
Undersize Frames The total number of frames received that were less
than 64 octets long (excluding framing bits, but
including FCS octets) and were otherwise well
formed.
Fragments The total number of frames received that were less
than 64 octets in length (excluding framing bits, but
including FCS octets) and had either an FCS or
alignment error.
Collisions The best estimate of the total number of collisions on
this Ethernet segment.
Table 4 Port Statistics (Continued)
Parameter Description
