2. Mount the device in the rack, using three rack-mountings screws.
Note: If the screws are not properly anchored, the strain of the cables connected to the Wireless
Hotspot Gateway rear panel connectors could pull out the Wireless Hotspot Gateway from the
wall.
2-2 Connecting the Antennas
The Wireless Hotspot Gateway provides two antenna connectors on the rear of the unit.
2-3 Installation Requirements
Before installing the Wireless Hotspot Gateway, make sure your network meets the following
requirements.
System Requirements
The Wireless Hotspot Gateway requires one of the following types of software:
z Windows 98 Second Edition/NT/2000/XP
z Red Hat Linux 7.3 or later version
z MAC OS X 10.2.4 or later version
z Any TCP/IP-enabled systems like Mac OS and UNIX (TCP/IP protocol installed)
z Standard phone line for xDSL modem
Or
Coaxial cable for Cable modem
z Web Browser Software (Microsoft I.E 5.0 or later version or Netscape Navigator 5.0 or later
version)
z One computer with an installed 10Mbps, 100Mbps or 10/100Mbps Ethernet card
z UTP network Cable with a RJ-45 connection (Package contents)
Note: Prepare twisted-pair cables with RJ-45 plugs. Use Cat.5 cable for all connections. Make sure
each cable not exceed 328 feet (Approximately 100 meters).
