– 123 –
KP-43T75/48S75/
53N77/53S75/61S75
RM-Y906
D654 8-719-057-96 DIODE D10SC6M-4012
D655 8-719-052-91 DIODE D4SBS4-F
D656 8-719-028-45 DIODE D2L20U-F
D657 8-719-028-45 DIODE D2L20U-F
D658 8-719-063-70 DIODE D1NL20U-TA
D659 8-719-063-70 DIODE D1NL20U-TA
D660 8-719-028-45 DIODE D2L20U-F
D661 8-719-991-33 DIODE 1SS133T-77
D662 8-719-991-33 DIODE 1SS133T-77
D663 8-719-991-33 DIODE 1SS133T-77
D664 8-719-981-94 DIODE MTZJ-T-77-2.7A
D665 8-719-991-33 DIODE 1SS133T-77
D666 8-719-991-33 DIODE 1SS133T-77
D667 8-719-032-12 DIODE D1NS6-TR
D668 8-719-110-61 DIODE MTZJ-T-77-24A
D669 8-719-921-86 DIODE MTZJ-T-77-13
D670 8-719-027-22 DIODE D3S6M-F
D671 8-719-027-22 DIODE D3S6M-F
D672 8-719-200-82 DIODE 11ES2-TA2B
D673 8-719-991-33 DIODE 1SS133T-77
D674 8-719-991-33 DIODE 1SS133T-77
D675 8-719-110-17 DIODE MTZJ-T-77-10B
D676 8-719-109-72 DIODE MTZJ-T-77-3.9B
D677 8-719-991-33 DIODE 1SS133T-77
D680 8-719-991-33 DIODE 1SS133T-77
D1501 8-719-109-89 DIODE MTZJ-T-77-5.6B
D1503 8-719-921-40 DIODE MTZJ-T-77-4.7B
D1504 8-719-110-08 DIODE MTZJ-T-77-8.2B
D1505 8-719-110-41 DIODE MTZJ-T-77-15B
D1506 8-719-110-41 DIODE MTZJ-T-77-15B
D1507 8-719-110-41 DIODE MTZJ-T-77-15B
D1509 8-719-110-41 DIODE MTZJ-T-77-15B
D1510 8-719-110-41 DIODE MTZJ-T-77-15B
D1513 8-719-110-41 DIODE MTZJ-T-77-15B
D1515 8-719-110-41 DIODE MTZJ-T-77-15B
D1520 8-719-109-93 DIODE MTZJ-T-77-6.2B
D1521 8-719-109-93 DIODE MTZJ-T-77-6.2B
D1522 8-719-924-16 DIODE MTZJ-T-77-24
D1523 8-719-924-16 DIODE MTZJ-T-77-24
D1525 8-719-908-03 DIODE GP08DPKG23
JW168 8-719-018-82 DIODE RGP02-20EL-6394
<FUSE>
F601 0 1-576-193-11 FUSE 6.3A/125V
F651 0 1-576-360-21 FUSE, MULTIPLE 4A
F652 0 1-576-360-21 FUSE, MULTIPLE 4A
<FERRITE BEAD>
FB651 1-410-396-41 FERRITE 0.45µH
FB655 1-410-396-41 FERRITE 0.45µH
FB656 1-410-396-41 FERRITE 0.45µH
FB657 1-410-396-41 INDUCTOR 0.45µH
<IC>
IC502 8-759-133-90 IC µPC339C
IC601 0 8-729-045-39 TRANSISTOR MX0842AB-F
IC651 8-759-103-93 IC µPC393C
IC652 8-759-701-84 IC NJM7905FA
IC653 8-759-701-75 IC NJM7805FA
IC654 0 8-749-012-13 IC DM-58
IC655 8-759-450-47 IC BA05T
IC1501 8-752-068-36 IC CXA1726AS
IC1502 8-749-014-37 IC STK392-150
IC1504 8-759-634-51 IC NJM4558D
IC1505 8-759-634-51 IC NJM4558D
IC1506 8-749-014-37 IC STK392-150
IC1507 8-759-634-51 IC NJM4558D
IC1509 8-759-593-33 IC LA78045
<COIL>
L501 1-412-533-21 INDUCTOR 47µH
L502 1-414-187-11 INDUCTOR 47µH
L503 1-459-104-00 COIL, DUST CORE
L504 0 1-419-082-11 COIL, HORIZONTAL LINEARITY
L505 1-412-552-11 INDUCTOR 2.2mH
L601 0 1-433-900-11 TRANSFORMER, LINE FILTER
L651 1-419-389-21 INDUCTOR 8.2µH
L652 1-419-389-21 INDUCTOR 8.2µH
L653 1-406-975-21 INDUCTOR 47µH
L654 1-410-396-41 FERRITE 0.45µH
L655 1-410-396-41 FERRITE 0.45µH
L656 1-412-525-31 INDUCTOR 10µH
L657 1-412-525-31 INDUCTOR 10µH
L658 1-412-525-31 INDUCTOR 10µH
L659 1-412-521-31 INDUCTOR 4.7µH
L660 1-412-521-31 INDUCTOR 4.7µH
L1501 1-412-533-21 INDUCTOR 47µH
L1502 1-412-533-21 INDUCTOR 47µH
L1509 1-412-533-21 INDUCTOR 47µH
L1510 1-412-533-21 INDUCTOR 47µH
L1511 1-412-533-21 INDUCTOR 47µH
L1512 1-412-533-21 INDUCTOR 47µH
L1513 1-412-525-31 INDUCTOR 10µH
L1514 1-412-911-11 FERRITE 0µH
L1515 1-412-911-11 FERRITE 0µH
<NEON LAMP>
NL501 1-517-778-21 LAMP, NEON
NL502 1-517-778-21 LAMP, NEON
NL503 1-517-778-21 LAMP, NEON
NL504 1-517-778-21 LAMP, NEON
NL505 1-517-778-21 LAMP, NEON
<IC LINK>
PS501 1-533-593-11 LINK, IC
PS1501 1-533-593-11 LINK, IC
PS1502 1-533-593-11 LINK, IC
PS1503 1-533-593-11 LINK, IC
PS1504 1-533-593-11 LINK, IC
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
G
Les composants identifies par
une trame et une marque
!
sont critiques pour la securite.
Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
! are criti-
cal for safety.
Replace only with part number
specified.
