EO1-11099
3. Outline of Preparation Procedure Before Operating
the ECR
This chapter shows the outline of set-up procedure of the ECR before actually starting
the ECR operation.
1
Remove the cash register from the carton, referring to
Chapter “2. Unpacking” on page 2. And take out all
the parts and accessories.
2
Remove the tapes and seals that are holding parts or
protecting the register surfaces.
Detach the Printer Cover and the Battery Cover, then
insert the batteries (3 pieces). After inserting the
batteries, attach the Battery Cover.
4
Plug the power cord of the register into a wall outlet.
Make sure that the outlet voltage matches that of the
power required for the register.
WARNING: Be sure to plug in the power cord first, then insert the
batteries.
3
5
Set the Mode Select Switch to the REG position.
WARNING: Be certain to insert the batteries enclosed in the
package. If they are not insert and the power is
turned OFF (including a power failure occurrence),
the sales data and the programmed data will be
cleared.
REG
OFF
SET
X
Z
