57
Operations
Load Media in Cutter Mode
1/7/10 Xi4™/RXi4™ User Guide P1009874-002
6. If your printer includes a media dancer assembly (1), thread the media under the media
dancer assembly roller. For all printers, thread the media under the media guide roller (
2)
and then the upper media sensor (
3).
7.
Important • Make sure that you thread the media under these components. If you thread
the media over them, the media obstructs the ribbon sensor and causes a false
RIBBON OUT error.
2
3
1
Caution • The cutter blade is sharp. Do not touch or rub the blade with your fingers.
Thread the media forward until it passes under the printhead assembly (1), under the
snap plate (
2), and through the cutter assembly (3).
1
2
3
