SFTP Service 213
Displaying help information
You can display help information about a command, such as syntax and parameters.
SFTP Configuration
Example
Network requirements
As shown in Figure 51,
■ An SSH connection is present between Switch A and Switch B.
■ Switch B serves as an SFTP server, with IP address 10.111.27.91.
■ Switch A serves as an SFTP client.
■ An SSH user name 8040 with password S5500 is created.
Network diagram
Figure 51 Network diagram for SFTP configuration
Configuration procedure
1 Configure Switch B (SFTP server)
a Enable the SFTP server.
[S5500] sftp server enable
b Specify SFTP service for SSH user 8040.
[S5500] ssh user 8040 service-type sftp
Table 196 Display help information about SFTP client commands
Operation Command Description
Enter system view system-view -
Enter SFTP client view sftp { host-ip | host-name } -
Display help information about SFTP client
commands
help [ command-name ] Optional
PC
IP address ： 10.111.27.91
SFTP Client
Switch B
SFTP Server
Switch A
PC
IP address ： 10.111.27.91
SFTP Client
Switch B
SFTP Server
Switch A
