MODULES (V35NX-2) > DIAL
Write security: 3; Read security: 5
Dials an Nx port that is configured to ignore DTR.
MODULES (V35NX-2) > DIAL > PRT
Read security: 5
Displays the port number. There are 2 available interfaces on the Dual Nx56/64 Option Module.
MODULES (V35NX-2) > DIAL > MODE
Write security: 3; Read security: 5
Configures the dialing mode. The following options are available:
MODULES (V35NX-2) > DIAL > DIAL
Write security: 0; Read security: 0
Signals the Nx port to dial/clear the call.
MODULES (V35NX-2) > DIAL > SRC ID
Write security: 3; Read security: 5
Indicates the SOURCE ID of the number to be dialed. Configure this field in the Nx INTERFACE
C
ONFIGURATION section of the DIAL PLAN.
MODULES (V35NX-2) > DIAL > NUMBER
Write security: 3; Read security: 5
Indicates the number to be dialed. Configure this field in the Nx INTERFACE CONFIGURATION section of the
DIAL PLAN.
MODULES (V35NX-2) > TEST
Write security: 4; Read security: 5
These options initiate different types of tests and display test results.
MODULES (V35NX-2) > TEST > PORT
Indicates operating port. There are 2 available interfaces on the Dual Nx56/64 Option Module.
DSR
— Off Off Off Off Off —
— = Do not care
Force On = On under all conditions
PERSISTENT Redial whenever the call is cleared or if the call fails.
O
NE TIME Attempt the call only once.
