the billing number of the calling party, and DNIS (Dialed Number Identification Service) is the called
party number.
DIAL PLAN (U-BRI) > USER TERM
Write security: 3; Read security: 5
This menu allows the user to define option parameters for ports which emulate a BRI connection.
DIAL PLAN (U-BRI) > USER TERM > IFCE CONFIG
Write security: 3; Read security: 5
Specifies the configuration parameters for the endpoint.
DIAL PLAN (U-BRI) > USER TERM > IFCE CONFIG > SWITCH TYPE
Defines the type of BRI switch the ATLAS 550 emulates. If connected to another ATLAS 550, both need
to be set to the same switch type. The following options are available:
DIAL PLAN (U-BRI) > USER TERM > IFCE CONFIG > SPID LIST
The port, acting as the network, must use a Service Profile Identifier (SPID) and phone number(s) in order
to satisfy the ISDN connection protocol expected by the user’s terminal adapter (TA).
• Lucent 5E • Northern DMS 100 • National ISDN
PHONE NUMBER
Write security: 3; Read security: 5
The phone number(s) assigned to this BRI phone line.
SPID NUMBER
Write security: 3; Read security: 5
This entry must match the SPID number(s) which has been set in the network’s ISDN switch (or in
the PBX) for this BRI line. A SPID must be entered for each phone number.
The ATLAS 550 does not support autoSPID detection software which some terminal
adapters offer.
CALLS
Write security: 3; Read security: 5
The number of calls (1 or 2) which can be received or sent on this number/SPID.
D64, D56, AUDIO, SPEECH
Write security: 3; Read security: 5
These options reflect the network provisions for this SPID. If the BRI was purchased with different
services provisioned for the SPIDs, then the call must match the services supported.
