Logic Analyzer Reference
1670G-Series Configuration Capabilities
1670G-Series Configuration Capabilities
The four analyzer models in each of the 1670GP-series offer a wide
variety of channel widths and memory depth combinations. The
number of data channels range from 34 channels with the
1673G, to a maximum of 136 channels with the
1670G. In addition, a half-channel acquisition mode is available which
doubles memory depth per channel while reducing channel width by
half.
The configuration guide below illustrates the memory depth/channel
width combinations in all acquisition modes with all analyzer models.
State Analyzer Configurations
State Analyzer Configuration Considerations
• Unused clock channels can be used as data channels.
• With Time or State tags turned on, memory depth is reduced by half.
However, full depth is retained if you leave one pod pair unassigned.
• Deeper memory configurations are available as options (see page 92).
Mode Memory 1670G 1671G 1672G 1673G
Full-channel
150 MHz
65536
(64K)
64K-deep / 136
chan. 132 data +
4 data or clock
64K-deep / 102
chan. 98 data + 4
data or clock
64K-deep / 68
chan. 64 data +4
data or clock
64K-deep / 34
chan. 32 data +
2 data or clock
