Console Interface
2-42
Port Priority Configuration
The default priority for all ingress ports is zero. Therefore, any inbound frames that
do not have priority tags will be placed in the low priority output queue. Default
priority is only used to determine the output queue for the current port; no priority tag
is actually added to the frame. You can use the 802.1P Port Priority Configuration
menu to adjust default priority for any port as shown below:
Alcatel OmniStack 8008
< 802.1P Port Priority Configuration >
Port Default Ingress Number of Egress
User Priority Traffic Class
-----------------------------------------------
10 2
20 2
30 2
40 2
50 2
60 2
70 2
80 2
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter Description
Port Numeric identifier for switch port.
Default Ingress User
Priority
Default priority can be set to any value from 0~7, where 0~3 specifies the low
priority queue and 4~7 specifies the high priority queue.
Number of Egress
Traffic Classes
Indicates that this switch supports two priority output queues.
