PC*MILER|AS/400 MVS User’s Guide
Validation Response:
Var Name Len Value Description
Extended Format
RESP-TYPE 2 PL Stop pick list
RESP-REF 10 Output Queue Name
Filler-3 3 3 blanks
RESP-MORE 1 Pos 16) M = more data to follow
Filler-3 3
Match 1 Pos 20)
L List of Cities
Y Exact match
N No match
Filler-2 2 2 blanks
RESP-Seq 4 Pos 23-26) Sequence for multiple responses
RESP-ERR 2 Pos 27-28 Error Code
E2 Place not found
NewÆ
ÆÆ
Æ RESP-MVS 3 Pos 29-31 (3 character PC*MILER Version)
Pos 32-38) Not Used
RESP-CIT 980 Array of 14 places 70 bytes each left justified
or
Error message if there is a problem
Filler 15
7.2.3 Point-to-point Miles (MI) Request and Response
1. (Request) The following are field parameters for requesting miles. The
purpose of the Mileage request is to allow the host application to retrieve
point-to-point miles. This type of request could be used for a quick mile
lookup from a host inquire program or for running several stop-off points in
a batch environment. The host dispatching software could generate this
request when a new trip is established.
Var Name Len Value Description
Extended Format
REQ-TYPE 2 MI Miles request
REQ-REF 10 Output Queue Name
(ALK uses ‘Q’ + the job number)
Trip Options Positions 13-22 Request Position
REQ-OPTION 1 Pos 1) S=Shortest
P=Practical
N=National/Practical
T=Toll Discouraged/Practical
5=53’ Trailer/Practical
B=Toll Discouraged/Practical
C=National Network/Practical
D=53 Foot Trailer/Practical
E=Toll Discouraged/National
Network/Practical
F=Toll Discouraged/53 Foot
Trailer/Practical
G=Toll Discouraged/Shortest
