Data Transfer Rates:
Power Supply: Bus power only (+5V from standard USB
connector, no external power cable required)
Bus Interface: USB 2.0 (Mass storage class device )
Disk Interface: IDE (UDMA mode 2)
Buffer Size: 128KB
RPM: 3600
Average Seek Time: 12ms
Sustained IDE data rate:
Case: 2 piece Aluminum alloy
Shock - non operating: 2000G (half sine wave, 1ms)
Shock - operating: 200G (half sine wave, 2ms)
Weight: 75g (approx 2.5oz)
Dimensions:
Random vibration - operating: 0.67G (5-500Hz, RMS)
Random vibration - storage: 3.01G (5-500Hz RMS)
Max temp - operating: 0 to 70 C
Max temp - storage:
Max humidity: 8% - 90% (non condensing)
Approvals:
rules for radiated and conducted emission, Part 15,
Subpart B, for class B equipment.
The MicroKey USB controller has been tested by the
USB-IF, and is approved as a USB 2.0 “High Speed
