6. How to Operate
57
6-9.2.1. Playback Devices
In order to playback, plug the USB devices such as external USB HDD, USB memory or
USB 2.0 DVD-RW (or CD-R/W) to the USB port or insert a recorded media (CD-R/W or
DVD-R/W) into the DVD-R/W drive.
When the devices are ready to playback, the Ready on the corresponding devices will be
displayed in shown in
[Fig.6-30].
▫ Click the mouse on a device among HDD, USB, CD-R/W and DVD-R/W that is displaying
the Ready (See
Fig.6-30). The corresponding LED will be lit in red when the device is
selected.
6-9.2.2. Set the Start Time
▫ Select the Date (year / month / day) on the calendar by clicking the mouse on the
highlighted character in black that turns to highlighted character in red (See
Fig.6-31).
The highlighted character in black indicates the dates and times that contains recorded
data, and the highlighted character in red indicates the selected dates and times.
▫ Select the month (year) by clicking the mouse on the ◄button or ► button.
[Fig.6-31 Calendar window]
[Fig.6-30 REPLAY DEVICE button]
HDD
USB
CD-RW
DVD-RW
